VacIon Plus 150 Pump
VacIon Plus 150 Pump
The VacIon Plus 150 L/s pump provides high pumping speed in a moderate footprint for mounting with a 6² Conflat flange, and is typically used in laboratories where ultra- and extreme high vacuum conditions are crucial. It is available with three types of elements. Diode elements are for general purpose UHV and XHV applications where highest hydrogen pumping speed is critical, and the system is seldom vented or prone to atmospheric leaks. StarCell elements handle a high amount of noble gases (better than noble diode) and hydrogen, and provides the highest speed and capacity for methane, argon and helium. Noble diode elements are used in general-purpose applications where pumping of residual argon and other noble gases is required.
Product Details
Features
- Available with StarCell, diode, and noble diode elements to provide the best pumping speed for different gases
- Available with ConFlat 6² non-rotatable flange, additional 6² ConFlat port, double-ended and side ports available with a choice of feedthroughs (Fischer, King, DESY, Varian, Safeconn) in different orientations
- No moving parts provide vibration free operation for sensitive applications
- Low leakage current provides stable vacuum pressure reading
- Low magnetic field for minimal system interference
- Vacuum processed at >400 °C and pinched off under vacuum to ensure cleanliness and vacuum integrity prior to installation
- Customizable with different high-voltage feedthroughs, body geometries, additional ports and pumping cell arrangements and available with optically shielded baffles, external heaters, and magnetic shielding to meet your needs
- SEM versions available with ultralow leakage current and high stability for minimal electrical interference
- Compact design body version available when dimensions are critical
