Cary 4000 UV-Vis spectrometer
Cary 4000 UV-Vis Spectrophotometer
Controlled by the Cary WinUV software, a Windows-based modular software, it can be ordered with specific modules for bio and pharma. The UV-Vis spectrophotometer has a number of optional accessories for liquid samples, like temperature control and multicell holders.
- UV-Vis & UV-Vis-NIR Instruments
Request a Quote
Product Details
- Measure beyond 8.0 absorbance units with reference beam attenuation
- WinUV software—a variety of applications from scanning to kinetics and thermal
- Versatile suite of accessories including temperature control, liquid and solid sample holders, solids autosamplers, multicell holders, and diffuse and specular reflectance accessories
- Variable slit widths (down to 0.01 nm) for optimum control over data resolution
- Large sample compartment with precision LockDown mechanism for quick changes of accessories
- Maximum light throughput using Schwarzchild coupling optics
- Minimal noise and stray light using a floating aluminum casting and double out-of-plane Littrow monochromator
- Extended dynamic range by attenuating the reference beam to be more equivalent to the sample's absorbance
- Nitrogen pumping—separate purging in the sample and monochromator compartments
| Control Software |
|
| Depth |
|
| Height |
|
| Light Source |
|
| Maximum Scanning Speed |
|
| Photometric Range (Abs) |
|
| Photometric System |
|
| Power Requirements |
|
| Spectral Bandwidth |
|
| Wavelength |
|
| Weight |
|
| Width |
|
| Z-height |
|
Double Beam Spectrophotometers
Double beam spectrophotometers are fast and accurate, using two beams of light—a sample beam and a reference beam—to correct instrument fluctuations in real-time.
