Micro-Electron Capture Detector (Micro-ECD)
for GC
Micro-ECD
Major design innovations neatly wrap ruggedness and reliability around unprecedented sensitivity and linearity. Spend less time maintaining the detector and more time running samples with the Agilent micro-ECD.
- GC Detectors
Product Details
- Small detection zone volume contributes to unsurpassed sensitivity
- MDL of 3.8 fg/mL of lindane for 8890 GC
- A broad dynamic linear range for confident, accurate quantitation of samples containing compounds with unknown concentrations, from femtograms to nanograms per microliter, e.g., linearity of 5 x 10^4 for lindane
- Compliant with U.S. EPA Contract Laboratory Program linearity requirements for pesticides over a range of 1 to 500 picograms/microliter
- Higher linear velocities through the detection zone reduce analyte residence time, decrease the chance of cell contamination, and improve uptime
- Hidden anode minimizes the chance for contamination to reach the anode
- Optimized electric field minimizes contamination effects on cell performance
- Variable sampling rate from 5 to 500 Hz makes it ideal for fast chromatography
- Application Notes
-
Analysis of Halogenated Hydrocarbons, Benzene, and Derivatives in Drinking Water
This application note shows the analysis of halogenated hydrocarbons, and benzene and its derivatives in drinking water per GB/T 5750.8-2022 using the Agilent 8697 headspace sampler and Agilent 8890 GC.
- Application Notes
- English
- 30 Apr 2024
- 1.17 MB
Analysis of Flavor Compounds in Beer using the Integrated Agilent 8697 Headspace Sampler with the Agilent 8890 GC System
Analysis of Flavor Compounds in Beer using 8697 headspace and 8890GC.
- Application Notes
- English
- 22 Feb 2024
- 620.35 KB
Analysis of 27 Halogenated Hydrocarbons and 11 Volatile Organic Compounds in Water
Analysis of 27 halogenated hydrocarbons and 11 volatile organic compounds in drinking water using an Agilent 8697 headspace sampler and an Agilent 8860 GC system with ECD and FID using nitrogen carrier gas.
- Application Notes
- English
- 02 Dec 2022
- 797.89 KB
GC/μECD Analysis and Confirmation of PCBs in Fish Tissue with Agilent J&W DB-35ms and DB-XLB GC Columns
Application note for GC/μECD Analysis and Confirmation of PCBs in Fish Tissue with Agilent J&W DB-35ms and DB-XLB GC Columns
- Application Notes
- English
- 27 Jan 2014
- 641.37 KB
GC-μECD Analysis and Confirmation of Contract Laboratory Protocol Pesticides in Olive Oil
Application note for GC-μECD Analysis and Confirmation of Contract Laboratory Protocol Pesticides in Olive Oil
- Application Notes
- English
- 24 Jan 2014
- 1.09 MB
Simultaneous Analysis of Greenhouse Gases by Gas Chromatography
Application note for simultaneous analysis of greenhouse gases by gas chromatography
- Application Notes
- English
- 24 Jan 2014
- 430.57 KB
Analysis of Organochlorine Pesticides in Drinking Water by Agilent 7820 Gas Chromatograph/Micro-Electron Capture Detector
Application note for the analysis of Organochlorine Pesticides in Drinking Water by Agilent 7820 Gas Chromatograph/Micro-Electron Capture Detector
- Application Notes
- English
- 21 Jan 2014
- 154.53 KB
A Direct Column-Performance Comparison for Rapid Contract Laboratory Program (CLP) Pesticide Analysis
Application note for a direct column-performance comparison for rapid contract laboratory program (CLP) pesticide analysis
- Application Notes
- English
- 15 Jan 2014
- 285.36 KB
Screening for Hazardous Chemicals in Homeland Security and Environmental Samples Using a GC/MS/ECD/FPD with a 731 Compound DRS Database
Application note for screening for hazardous chemicals in Homeland Security and Environmental Samples Using a GC/MS/ECD/FPD
- Application Notes
- English
- 13 Jan 2014
- 311.66 KB
Rapid Analysis of CLP Pesticides Using High-Temperature Agilent J&W DB-CLP1 and DB-CLP2 Columns
Agilent J&W DB-CLP1 and DB-CLP2 column pair performs rapid, high-resolution separations of CLP pesticides, US EPA methods, and similar semi-volatile mixtures
- Application Notes
- English
- 23 Sep 2012
- 482.30 KB
- Quick Reference Guides
-
ECD Return and Disposal
This document describes how to dispose of a used electron capture detector (ECD) when it is no longer needed or at the end of its operating life.
- Quick Reference Guides
- English
- 13 Apr 2023
- 165.84 KB
Gas Chromatography Detectors
Highlights the features of and differences between GC detectors.
- Quick Reference Guides
- English
- 10 Jun 2022
- 161.49 KB
- Site Preparation Checklists
- User Manuals
