TwisTorr 305 FS Turbo Pump
TwisTorr 305 FS Turbo Pump
The TwisTorr 305 FS turbo pump is ideal for academic research/particle accelerators (pump and controller can be up to 100 m apart) where compression ratio is an important factor contributing to very low base pressure. The pump’s low noise and vibration level make it a perfect solution for sensitive instruments, mass spectrometry, electron microscopes, and surface analysis applications.
- Turbo Pumps
Product Details
- High compression ratios for light gases enabling low base pressure
- Hydrocarbon free for clean vacuum system
- Remote controller allows operation from 100 m away
- Low vibration and noise levels—41 dB(A)—for a comfortable working environment and operation in sensitive experiments
- Compact size and installation in any position allow easy integration
- Maintenance-free bearings for zero operating cost
- Gauge reading capability for system pressure monitoring
- Ready for wireless control via Vacuum Link app for pump operation on the go
- Radiation and magnetic field-proof design with no embedded electronics allows operation in demanding magnetic field and radiation environments
- Low electromagnetic emission guarantees no interferences with application process
| Ambient Operating Temperature |
|
| Ambient Storage Temperature |
|
| Base Pressure |
|
| Compression Ratio H2 |
|
| Compression Ratio He |
|
| Compression Ratio N2 |
|
| Cooling Method |
|
| Flange Type |
|
| Foreline Flange Size |
|
| Foreline Tolerance - N2 |
|
| Maximum Gas Throughput - N2, Water Cooling |
|
| Noise Level |
|
| Nominal Rotation Speed |
|
| Operating Position |
|
| Pumping Speed - Ar |
|
| Pumping Speed - H2 |
|
| Pumping Speed - He |
|
| Pumping Speed - N2 |
|
| Recommended Forepump Capacity |
|
| Standards and Certifications |
|
| Start Up Time |
|
| Weight |
|
