Rack Controller for TwisTorr 84 FS Turbo Pump

Features

Ready for Vacuum Link app to give full pump control through your mobile phone
Active gauge reading capability for system pressure monitoring
Pump cable lengths up to 100 m long for remote controller mounting
RS232/RS485/Profibus communication protocols for easy integration
Analog I/O provides accurate control of the pump
Remote control with A-plus software enables pump operation, control, and recording of system parameters (i.e., pressure)
Rack-mounted design for easy integration
Vent valve and cooling fan driving to get full vacuum system control
Universal voltage (100–240 V) enables worldwide operation
Shipped without a power cord, to be ordered separately

Specifications


Configuration	Remote controller, rack-mounted
Maximum Pump Cable Length	100 m
Operating Environment Relative Humidity	90 % maximum non condensing humidity
Operating Environment Temperature	5° C to 45° C
Pump Model Compatibility	TwisTorr 84 FS Turbo Pump
Standards and Certifications	EN 61010 -1 EN 55011 (Class-A) EN 61000-3-2, EN 61000-3-3, EN 61000-6-2, EN 61000-4-2,3,4,5,6,11, 8
Weight	1.7 kg
